Medical Device Calibrations
Calibrating medical equipment is crucial for accurate healthcare. It ensures precise diagnosis, monitoring, therapy, and treatment. Proper calibration prevents misdiagnoses caused by poorly adjusted machines. For human health, absolute accuracy is essential, making standard calibration of hospital systems imperative. This process aims to provide advanced and error-free healthcare for the well-being of the population. We, Choksi Lab, ensure the service to the medical sector with high precise and trust. We also provide engraving (permanent marking id number) on volumetric apparatus on customer request.
We provide services for various instruments, including but not limited to:
- Autoclave
- Oxygen pressure gauge
- Centrifuge machine
- BP apparatus
- Nebulizer
- Trans illuminator light source
- Radiant Warmer
- Electronic Tourniquet
- Boyels apparatus
- OT light
- Blade
- Freezer
- Electrode pH meter
- Weighing scales (baby/ store)
Scope of Services:
| Instruments | Range | Method for calibration |
|---|---|---|
Autoclave
(Pressure
Temperature
Time) | -0.87 bar – 600 bar | Using Digital Dead weight/ Pressure Gauge, 6 ½ digit multimeter and Pneumatic Pressure Pump by comparison method |
Oxygen pressure gauge | 0 – 300 bar | Using oxygen cylinder and pressure gauge by comparison method |
Centrifuge machine | 30 rpm – 25000 rpm | Using Digital Tachometer by comparison method |
BP apparatus | 0- 300 mmHg | Using digital manometer by comparison method |
Nebulizer | 0- 100 mbar | Using digital manometer by comparison method |
Trans illuminator light source | 100 – 10000 lux | Using lux meter comparison method |
Radiant Warmer | 30 °C – 50 °C | Using Standard RTDs and temperature indicator by Comparison Method |
Micro Balance (d= 0.001mg), Class I and coarser | 0.05mg – 20 g | Using Standard Weights of E1 and E2 class accuracy |
Weighing scales (baby/ store) | 0.5 mg – 50 kg | Using Standard Weights (E1 class – F1 class) |
Electronic Tourniquet (time) | 0- 24 hr | Comparison by Stop watch |
Boyels apparatus | 0-20 bar | Using pressure gauge and pump by comparison method |
OT light | 100 – 10000 lux | Using lux meter comparison method |
Blade (measurement) | 0- 25 mm | Using profile projector & micrometer (Least count 0.001 mm) (Angle: 1minute) |
Freezer | -80 °C – 200 °C | Using SPRT with Thermometer, Dry Well Calibrator by Comparison Method |
Electrode pH meter | 0- 50 mV | Using multi function calibrator by comparison method |
