Plywood
Plywood is a composite wood panel made by layering thin sheets of wood veneer. These layers are glued together with each adjacent layer's wood grain rotated perpendicular to enhance strength and stability. Plywood is widely used in construction, furniture, and various other applications due to its versatility and structural integrity.
Synthetic resin adhesive is a versatile bonding agent commonly used in carpentry and woodworking. It is formulated with synthetic resins to provide strong and durable bonds between various materials, such as wood and laminates.
Plywood for general purpose is a versatile engineered wood product made by layering thin sheets of wood veneer. It exhibits strength and stability due to its cross-grain construction, making it suitable for various applications in construction, furniture, and DIY projects.
Marine plywood is a specialized type of plywood designed for high-moisture environments, such as boat construction and outdoor projects. It is made with waterproof adhesives and high-quality wood veneers, ensuring durability and resistance to rot, fungal decay, and delamination.
Veneered decorative plywood is crafted by overlaying a thin layer of aesthetically pleasing wood veneer onto a base of standard plywood.
lockboard is a type of engineered wood composed of a core made of wooden blocks or strips sandwiched between two layers of veneer. It is known for its strength, stability, and resistance to warping, making it a popular choice for furniture and interior applications.
Wooden flush door shutters with a solid core type refer to doors that have a solid and dense inner core, providing stability and durability. These doors typically consist of a solid wood or engineered wood core.
Plywood for concrete shuttering works is specifically designed for temporary formwork in construction. It offers a smooth surface, dimensional stability, and strength, providing an ideal mold for pouring concrete and ensuring a high-quality finish in the final construction.
Type Of Tests At Performed at CLL Lab
| Synthetic Resin Adhesive | Plywood for General Purpose | Block Board | Plywood for Veneered decorative |
|---|---|---|---|
| SIX cycles, each cycle consisting of 8 h boiling In water and there after drying at 65 ± 2°C for 16h | Workmanship and Finish | Dimension | Moisture Content |
| Three cycles. each cycle consisting of 8 h boiling in water and there after drying at 6S± 2 °C for 16 h | Glue Adhesion | Dimensional Changes Caused by Humidex | Water Resistance Test |
| Three cycles. each cycle consisting of 3 h at 60± 2°C an water and there after drying at 65± 2°C for 8 h | Static Bending test (MOE&MOR) | Resistance to Water | Dimension |
| Preparation of Test Pieces | Mycological Test | Adhesion of Plies | - |
| Visual examination | Water Resistance Test | Mycological Test | - |
| Forcible separation of plies | Moisture Content | 5 Modulus of Rupture and Modulus of Elasticity | - |
| Acidity and Alkalinity (PH) | Dimension | Spot Test | - |
| Marine Plywood | Wooden flush door | Plywood for concrete shuttering works | MDF Board |
|---|---|---|---|
| Dimension | Dimensions and squareness test | Dimensions | Density (Kg/m3) |
| Workmanship and Finish | General flatness test | Workmanship and Finish | Moisture content, percent |
| Moisture Content | Local planeness test | Moisture Content | Variation from mean density |
| Glue Adhesion in Dry State | End immersion test | Glue Adhesion in Dry State | Water absorption percent |
| Glue shear strength | Knife test | Glue shear strength | Linear expansion (swelling In water) percent |
| Adhesion of plies | Glue adhesion test | Adhesion of plies | Modulus of rupture |
| Water Resistance/Mycological Test | Flexure test | Water Resistance Test | Modulus of elasticity |
| Tensile/Static Bending Strength | Impact indentation test | Tensile Strength |
