Thermal Calibrations
Calibrating temperature-measuring instruments is vital for industries like healthcare and manufacturing. Highly accurate devices are used to set temperature scales. Choksi Laboratory Calibration Services caters to a variety of instruments to fulfil our customers' exact temperature measurement needs.
We provide services for various instruments, including but not limited to:
- Refrigerators
- Deep freezer
- Temperature Gauge
- Thermo Hygrometer
- Liquid in Glass Thermometer
- RTD/ Thermocouple
- Temperature Sensor w/wo Indicators
- Humidity Chambers (Single/ multi point)
- Temperature Calibrators
- Furnace
- Chamber
- Temperature Bath
- Incubator
- Liquid Bath
- Dry Well Block
- Cold Room (Multi position)
Scope of Services:
| Parameter | Range | Method for calibration |
|---|---|---|
| Thermo Hygrometer@50% RH | 15 °C - 40 °C | Using RH and Temperature controlled Chamber, Digital Thermo Hygrometer by Comparison Method |
| Thermo Hygrometer@25°C | 30 % RH - 90 % RH | Using RH and Temperature controlled Chamber, Digital Thermo Hygrometer by Comparison Method |
| Liquid in Glass Thermometer | -20 °C - 250 °C | Using SPRT with Thermometer, low Temp. Liquid bath by Comparison Method |
| RTD/Thermocouple, Temperature Sensor with or without Indicators, Temperature Gauge | -25 °C - 650 °C | Using SPRT withThermometer, low Temp. Liquid bath by Comparison Method |
| RTD/Thermocouple, Temperature Sensor with or without Indicators, Temperature Gauge | 200 °C - 1200 °C | Using S-Type Thermocouple with Thermometer, Dry Well Calibrator by comparison method |
| Humidity Chambers (Single/ multi point) | 15 °C - 40 °C | Using Temperature/Humidity Data Loggers by Comparison Method |
| Humidity Chambers (Single/ multi point) | 30 % RH - 90 % RH | Using Temperature/Humidity Data Loggers by Comparison Method |
| Humidity Indicator with Sensor of Chamber (Single Position) | 30 % RH - 90 % RH | Using Digital Thermo Hygrometer by Comparison Method |
| Temperature Indicator with Sensor of Chamber (Single Position) @ 50 %RH | 15 °C - 45 °C | Using RH Digital Thermo Hygrometer by Comparison Method |
| Deep freezer, Refrigerators, Incubator, Temperature Bath, Temperature Calibrators, Chamber, Dry Well Block, Liquid Bath, Cold Room (Multi position) | -25 °C - 25 °C | Using Standard RTDs and Multi channel data loggers by Comparison Method |
| Temperature Bath, Temperature Calibrators, Chamber, Dry Well Block, Liquid Bath, Oven Furnace (Multi position) | 25 °C - 1200 °C | Using Standard RTDs(minimum 9 sensors), and Multi channel data loggers by Comparison Method |
| Temperature Indicator with sensor of freezer, Incubator (for non medical purpose), Liquid Bath, Dry Well Block, Chambers | -80 °C - 200 °C | Using SPRT with Thermometer, Dry Well Calibrator by Comparison Method |
| Temperature Indicator with sensor of Oven, Furnace, Liquid Bath, Dry Well Block, Chambers, Incubator | 400 °C - 1200 °C | Using R – Type Thermocouple with Calibrator, Dry block furnace by Comparison Method |
| Thermocouple, Temperature Sensor with or without Indicators, Temperature Gauge | 400 °C - 1200 °C | Using R – Type Thermocouple with Calibrator, Dry block furnace by Comparison Method |
